Is there something wrong with the loudspeaker on your Google Pixel 8? Learn how to replace the faulty Loudspeaker of your Google Pixel 8 with our step-by-step guide!
A phone's loudspeaker provides audio output during communication and multimedia tasks. A faulty loudspeaker will affect the output performance of your Google Pixel 8. We have to replace the defective Loudspeaker of your Google Pixel 8 to restore its audio performance.
Let's proceed to replace the Loudspeaker of your Google Pixel 8.
Step 1 Gather Mobile Repairing Tools
Prepare all these useful mobile repairing tools to replace the Loudspeaker of your Google Pixel 8:
- A Hot gun or Hair Dryer to heat the phone
- A suction cup to create a gap between the screen and phone frame
- A plastic opening pick or tool to slice the adhesive
- A set of screwdrivers to unfasten the screws
- A spudger to pry up the press connectors
- A pair of tweezers to hold and remove the mobile components
- Isopropyl Alcohol to melt old adhesive
- Cotton Bud to apply Isopropyl Alcohol
- Lint-free cloth to wipe
Step 2 Prepare Your Pixel 8 For Disassembly
First of all, unplug all cables from the phone and follow these steps to power off your Google Pixel 8:
- Press and hold the power and volume up button together
- Wait for a few seconds
- A power menu will appear on the screen.
- Tap on the power off option to turn off your Pixel 8.
Step 3 Heat Your Pixel 8
- Take a hot air gun or hair dryer.
- Adjust medium heat settings on the hot air gun or hair dryer. You can also use a hot plate to heat your Pixel 8.
- Heat the phone edges for 5 to 10 minutes.
- Keep the hot air gun or hair dryer at least 5 to 7 cm away from your phone.
- Heat will soften the adhesives present around all the edges of your phone.
- Do not overheat your Pixel 8 to avoid hardware damage.
Step 4 Fix A Suction Cup
- Apply a suction cup near the bottom side of your phone’s screen.
- Hold the handle of the suction cup in your hand.
- Pull the handle until a gap forms between the screen and the phone’s frame.
Step 5 Use A Plastic Opening tool
- Get a plastic opening tool and pick.
- Use a meter rule to mark 3mm on the plastic opening tool.
- Insert the opening tool into the gap only up to 3mm into the gap between the screen and phone frame.
- There is a display cable on the left side of your Pixel 8. Do not insert the opening tool over 3mm to avoid physical damage.
- After inserting the pick, remove the suction cup from the screen.
Step 6 Slice Lower Edge Adhesive
- Move the opening pick from one lower corner to the other to slice the bottom adhesive.
Step 7 Cut The Left Side Adhesive
- Keep sliding the plastic opening pick from the lower left to the upper left corner to cut the left adhesive.
Step 8 Cut Through The Upper Adhesive
- Slide the pick from the upper left to the upper right corner of the phone to slice upper-edge adhesives.
Step 9 Remove Right Side Adhesive
- Now move the opening pick from the upper right to the lower right corner to cut the right side adhesive.
Step 10 Prop Up The Screen
- Open the screen like a book and hold it in an upright position.
- Always remember the screen is connected to the phone’s frame.
Step 11 Remove The Screen Cable Cover
- Lift and remove the screen cable cover with a spudger or a prying tool.
Step 12 Disconnect The Screen
- Unclip the screen’s press connector with a spudger.
Step 13 Detach The Screen
- Detach the screen from the phone frame.
- Keep it aside in a safe place as you may need it during the reassembly of your Pixel 8.
Step 14 Peel Off The Plastic Buffer
- Pry up the black plastic buffer with the help of a spudger or prying tool.
- Hold the plastic buffer with a pair of tweezers or your fingers.
- Now peel it.
Step 15 Unscrew The USB-C Port Bracket
- There are two 5 mm-long screws, securing the USB-C Port to its recess.
- Keep the screws in a safe place.
Step 16 Separate The USB-C Port Bracket
- Hold the USB-C port bracket with a pair of tweezers.
- Remove the USB-C Port Bracket from its recess.
Step 17 Unscrew The Loudspeaker
- Remove the 5mm-long screw of the Loudspeaker with a screwdriver.
Step 18 Remove The Loudspeaker
- Use a spudger to pry up the Loudspeaker.
- Remove the Loudspeaker from its recess.
Step 19 Install The New Speaker
- Install the new Loudspeaker of your Pixel 8 into its recess.
- Tighten up the 5mm-long screw of the Loudspeaker.
Step 20 Reassemble Your Pixel 8
- Dip a cotton bud into the isopropyl alcohol.
- Rub the cotton bud around the edges of the phone frame.
- Isopropyl Alcohol will melt the old adhesive around the edges of your Pixel 8.
- Wipe the old adhesive with a clean cotton cloth.
- Reconnect all the components and fasten up the screws.
- Reconnect the screen press connector. Fix the screen's press connector cover.
- Apply new adhesive around the edges of the phone frame.
- Carefully attach the screen to the phone frame.
Wrapping Up
We have successfully guided you through the process of replacing the Loudspeaker on your Google Pixel 8. Turn on your Google Pixel 8 and test the new loudspeaker of your phone by playing music.
